best accuracy：<0.002°
angular resolution：0.0005°
ip54 protection class
maximum measurement range：±30°
data storage function
absolute / relative measurement switchable
customers can calibrate the zero point by themselves
product description
scope of application
parameter
dimensions
download
| dmi850 | parameter | unit |
| measurement range | ±30 | ° |
| measuring axis | single-axis | |
| bestaccuracy | <0.002 (＜5°)、<0.003 (5°-30°) | °(rms) |
| resolution | 0.0005 | ° |
| measurement mode | two modes can be set: degree, mm / m | / |
| lcd | 64 color true color luminous display | / |
| lcd visible size | l60*w45 | mm |
| operating temperature | -10°～ 70℃ | °/℃ |
| working humidity | 85 | %rh |
| power supply | 2a no.5 battery | / |
| battery continuous working time | 6 | h |
| anti-vibration | 10g @ 11ms, triaxial and same (half sine wave) | / |
| impact resistance | 10grms、10～100hz | / |
| weight | 1200 | g |
| protect class | ip54 | / |
| material | anodizing of aluminum alloy | / |
| size | l140*w140*h45mm | mm |
l140×w140×h45mm
two-sided strong magnetic adsorption installation
* please contact the online sales engineer to obtain the product specification of rion, or email sales@rion-tech.net to obtain it.
