auto-angle interleaved compensation function
auto temperature drift compensation
user can calibrate by himself
built-in recharge industry battaries
night vision fours colors screen
ip54 protection class
product description
scope of application
parameter
dimensions
download
| parameters | dmi410 | dmi420 |
| measurement axis | single axis | dual axis |
| angle measurement range | ±180 ° | ±90 ° |
| angle measurement accuracy | 0.05 °（full range） | 0.05 °（full range） |
| angle measure resolution | 0.01° | 0.01° |
| mm/m measure range | ±999.9mm/m | ±999.9mm/m |
| mm/m measurement accuracy | 0.9mm/m(full range) | 0.9mm/m(full range) |
| mm/m measurement resolution | 0.1mm/m | 0.1mm/m |
| lcd visible area size | l40*w32mm | |
| working temperature | -10℃～ 70℃ | |
| working humidity | 85%rh | |
| power supply | 3.7v charging lithium battery | |
| ideal charging time | 3h | |
| battery continuous working time | 8h（±0.5） | |
| data output signal | standard5pin usb connector | |
| anti-vibration | 10g@11ms、3 axial direction (half sinusoid) | |
| impact resistance | 10grms、10～100hz | |
| waterproof level | ip54 | |
| material | metal aluminum | |
| size | l83*w53*h19.2mm | |
| weight | ≤140g | |
l83×h53×w19.2mm
* please contact the online sales engineer to obtain the product specification of rion, or email sales@rion-tech.net to obtain it.
